Description
Revolutionise your connectivity with the Thuraya IP NEO, a portable satellite terminal designed for high-performance communication in the toughest environments. Built on Cobham’s trusted hardware platform, the IP NEO delivers broadband speeds of up to 1024 kbps, making it ideal for applications like VoIP calls, video conferencing, telemedicine, and IoT/M2M solutions.
Weighing just 2.2 kg, the IP NEO is compact enough to fit in a backpack yet powerful enough to keep operations running smoothly in remote and off-grid locations. With its IP55-rated magnesium casing, screw-on connectors, and built-in Wi-Fi hotspot, it’s engineered for durability, portability, and seamless connectivity.
Government agencies, NGOs, oil and gas companies, healthcare providers, and media professionals trust the IP NEO for mission-critical communication. From disaster relief to field exploration, this terminal empowers you to stay connected, informed, and in control.
Key Features:
- Speeds up to 1024 kbps over the Thuraya 4-NGS satellite
- Portable and battery-operated (only 2.2 kg)
- Built-in Wi-Fi hotspot and Thuraya Connect App compatibility
- IP55-rated durable casing for harsh conditions
- Easy setup from backpack to broadband in seconds
-
Supports ISR, C2, IoT/M2M, video transmission, eLearning, and more
Wherever your mission takes you, the Thuraya IP NEO ensures you never lose your link to the world.
Read More
Specification
| Category | Specification |
|---|---|
| Device | |
| Dimensions (H × W × D) | 225 × 225 × 61.5 mm |
| Weight (incl. battery) | 2.2 kg |
| Data & Voice | |
| Data (Thuraya 4-NGS) | Up to 1024 kbps (Rx/Tx) at > 5° elevation |
| Data (Thuraya 2/3) | Up to 444 kbps (Rx/Tx) at > 5° elevation |
| Voice (Thuraya 4-NGS) | Standard VoIP, Embedded SIP Server |
| RF & GNSS | |
| Frequencies (Tx) | 1626.5–1660.5 MHz |
| Frequencies (Rx) | 1525.0–1559.0 MHz |
| GNSS | GPS, Galileo, Beidou, Glonass |
| Languages & Approvals | |
| Languages | ENG, AR, FR, POR, ES, RU, JP, CN |
| Approvals | CE, RED, RoHS, WEEE, FCC, UL, RCM; Thuraya Type Approval |
| Power | |
| DC input range | 12–24 VDC (max. 10.8–33.6 VDC) |
| PoE input | PoE (802.3bt Type 3 Class 6 via RJ45) |
| PoE output | PoE (802.3at Type 1 Class 2 via RJ45) |
| Power consumption | Standby/Transmit: 4.5 W / 22 W (typical); During charging: 75 W (max.) |
| AC/DC power supply (input) | 100–240 VAC, 47–63 Hz, 64 W |
| AC/DC power supply (output) | 19 VDC |
| Battery type | Lithium-ion (rechargeable) |
| Battery (nom. voltage / capacity) | 10.8 V / 6.9 Ah |
| Battery run time (standby) | Up to 38 hours* |
| Battery run time (receive) | Up to 4 hours @ 1024 kbps* |
| Battery run time (transmit) | Up to 2 hours @ 1024 kbps* |
| Recharge time | < 3 hours (0–100%) |
| Charge temperature | 0°C to 45°C |
| Environmental | |
| Operating temperature (ambient) | −21°C to +55°C |
| Storage temperature | −21°C to +50°C |
| Ingress protection | IP55 compliant |
| Interfaces | |
| WLAN access point | 802.11 b/g/n/ac |
| Ethernet | 2 × RJ45: 1 × PoE input (external power), 1 × PoE output (IP Handset) |
| User interface | 2 × LED (Status, WLAN), Power Button, Reset Button, Web Interface |
| Features | |
| Companion app | Thuraya Connect App (Android / iOS) |
| Router & management | Webserver, NAT Router, Admin control (password protected), DHCP, Network Management, Remote Management, PPPoE |
| Package Contents | |
| In the box | IP NEO C Terminal with embedded Lithium-Ion Battery; AC/DC Power Supply; Euro Power Cord; EU to UK Converter; Quick Start Guide; Ethernet Cable |
* On Thuraya 4-NGS.
